Praktica TL 5B
Praktica Super TL1000 Praktica super TL 500 Praktica MTL 5 Praktica MTL 5 Pentacon Italia REVUEFLEX TL25 Praktica Super TL1000 1st variation Praktica "noname" Praktica MTL3 Praktica PM3 Praktica NOVA II Praktica TL3 Praktica MTL5 Revue ML Praktica MTL 5B Praktica MTL NOVA B Praktica TL 5B Revue ML 1st variation Praktica DTL 5 Praktica MTL 50



Praktica TL 5B
Producer data
Producer Kombinat VEB Pentacon Dresden responsible constructor Rolf Noack
production period December 1985 to December 1989 no of produced cameras as a part of Praktica MTL 5B series 567,831
Technical properties of the camera
shutter type mechanically controlled vertical-moving metal-blade focal plane shutter exposure time
(possible settings)
B, 1/1, 1/2, 1/4, 1/8, 1/15 1/30, 1/60, 1/125, 1/250,1/500, 1/1000
view finder fixed eye-level view finder (Pentaprism) with new field lens with triple rangefinder wedge, truncated microprism screen, groundglass field, built-in shutter speed meter mirror instant-return mirror
film transport / frame counter quick-release lever (black), Pentacon Loading-System, fold-out rewind crank (black), auto-zeroing frame counter lens mount M42x1
self timer mechanically, approx. 8 sec battery VARTA LR44
metering system TTL-metering using stopped-down metering controlled by a switch beside the lens mount above the shutter release knob flash system X-synchronisation (1/125), accessory shoe at the top of the pentaprism, none coaxial flash socket
flash indication none aperture reflection into view finder none
general comments
bulletsmooth, unruffled leatherette with stampings
bulletrelabelled with a TL 5B-badge
bulletMTL 5B-version for the U.K. Market (via C.Z. Scientific Instruments Ltd., Elstree Way, Borehamwood, Herts WD6 INH)
collection data
Hummel-No none Kadlubek-No. none
body no. 728806 lens no. 6696100
lens type Pentacon auto 1.8/50 Multi Coating purchase price 64€
advertising



manual

under construction
