| Praktica
IVF |
| Producer data |
| Producer |
VEB Kamera- und Kinowerke
Dresden; since March 1964 VEB Pentacon Dresden Kamera- und Kinowerke |
responsible constructor |
Horst Strehle |
| production period |
December 1963 to January 1966 |
no of produced cameras |
20,445 |
| Technical properties of the camera |
| shutter type |
mechanically controlled horizontal-run
rubberised cloth-blind type shutter with twin settings for fast and slow
speeds |
exposure time
(possible settings) |
B, 1/2, 1/5, 1/10, 1/25, 1/50, 1/100,
1/200,1/500 |
| view finder |
fixed eye-level view finder (Pentaprism)
with fresnel-screen with split-image range finder and ground-glass ring |
mirror |
no instant-return mirror |
| film transport / frame counter |
knob film advance, loose film take-up
spool (plastic), manual frame
counter, divided rewind knob as fold-out lever for rewinding, rapid winder at
the camera bottom |
lens mount |
M42x1 |
| self timer |
none |
battery |
none |
| metering system |
none |
flash system |
X- and F-synchronisation with
two flash coaxial sockets at the front of the camera body |
| flash indication |
none |
aperture reflection into view finder |
none |
| general comments |
|
| collection data |
| Hummel-No |
145 |
Kadlubek-No. |
KWE 1260 |
| body no. |
485068 |
lens no. |
4236189 |
| lens type |
Meyer-Optik Görlitz Domiplan
2.8/50 |
purchase price |
40€ |
| advertising |
|
manual |
|

|
