REVEUFLEX TL I
Praktica super TL 3 Praktica MTL 3 Praktica MTL 3 cut model FOTICON MTL 3 REVEUFLEX TL I REVEUFLEX TL 25 Praktica PLC3 Praktica PLC3 noname Praktica VLC 3 Praktica EE3 Praktica DTL 3



REVUEFLEX TL I
Producer data
Producer Kombinat VEB Pentacon Dresden responsible constructor Rolf Noack
production period 1979 no of produced cameras as a part of Praktica MTL 3-series (865,395)
Technical properties of the camera
shutter type mechanically controlled vertical-moving metal-blade focal plane shutter exposure time
(possible settings)
B, 1/1, 1/2, 1/4, 1/8, 1/15 1/30, 1/60, 1/125, 1/250,1/500, 1/1000
view finder fixed eye-level view finder (Pentaprism) with Fresnel lens with microprism and split-image range finder as focusing screen, built-in shutter speed meter with (+/-)-symbol mirror instant-return mirror
film transport / frame counter black quick-release lever, Pentacon Loading-System, fold-out rewind crank, auto-zeroing frame counter lens mount M42x1
self timer mechanically, approx. 10 sec battery VARTA V 625
metering system TTL-metering using stopped-down metering controlled by a switch beside the lens mount above the shutter release knob flash system X-synchronisation (1/125), accessory shoe at the top of the pentaprism, without coaxial flash socket at the camera body for dual flash systems
flash indication none aperture reflection into view finder none
general comments
bulletspecial export version for Fa. Quelle, Nürnberg (West Germany)
bulletversion with black varnishing at the camera bottom
bulletblack rewind bottom
bulletblack quick-release lever
collection data
Hummel-No 201A Kadlubek-No. REV 0781
body no. 195293 lens no. 10248766
lens type AUTO REVUENON 1.8/50 Multi Coating purchase price 40€
advertising



manual

under construction
