Praktica DTL 2
Praktica LTL 3 Praktica LTL 3 Praktica LTL 3 black Foticon black Praktica PLC 2 Praktica PLC 2 black Praktica L 2 Praktica L 2 half frame Praktica L 3 ENDO Praktica ENDO noname Praktica ENDOSKOPIE 2 Praktica LB 2 Praktica VLC 2 Praktica VLC 2 half format Praktica RTL ASTRO/MICRO CONVERTIBLE Praktica EE2 SR899 - GSK Sonderobjektiv SO 2.2 B Praktica DTL 2



Praktica DTL 2
Producer data
Producer Kombinat VEB Pentacon Dresden responsible constructor Rolf Noack
production period October 1978 to February 1979 no of produced cameras 158
Technical properties of the camera
shutter type mechanically controlled vertical-moving metal-blade focal plane shutter exposure time
(possible settings)
B, 1/1, 1/2, 1/4, 1/8, 1/15 1/30, 1/60, 1/125, 1/250,1/500, 1/1000
view finder fixed eye-level view finder (Pentaprism) with Fresnel lens and microprism range finder as focusing screen, built-in light-scale based on four LED-arrow elements in two groups  mirror instant-return mirror
film transport / frame counter quick-release lever, Pentacon Loading-System, fold-out rewind crank, auto-zeroing frame counter lens mount M42x1
self timer mechanically, approx. 10 sec battery VARTA V 21 PX
metering system TTL-metering using stopped-down metering controlled by a switch beside the lens mount above the shutter release knob flash system X-synchronisation (1/125), accessory shoe at the top of the pentaprism
flash indication none aperture reflection into view finder none
general comments
bulletbattery-test LED on the top of the camera localized next to the rewind bottom
collection data
Hummel-No 198 Kadlubek-No. KWE 1480
body no. 001082 lens no. 6816158
lens type Pentacon electric 1.8/50 purchase price 4000€
advertising



manual

under construction
