No Name (Pentacon, second variant, export variant, large tower, original Consol)
Producer data
Producer VEB Zeiss Ikon Dresden responsible constructor Walter Henning
production period April 1956 to August 1956 no of produced cameras part of Contax D series (69,599)
Technical properties of the camera
shutter type mechanically controlled horizontal-run rubberized cloth-blind type shutter exposure time
(possible settings)
B, 1/1, 1/2, 1/5, 1/10, 1/20, 1/50, 1/100, 1/200,1/500, 1/1000
view finder fixed eye-level view finder with condenser type ground-glass focusing screen (´Stevens Screen´) mirror no instant-return mirror
film transport / frame counter knob film advance, loose film take-up spool, manual frame counter lens mount M42x1
self timer mechanically, ~10s battery none
metering system none flash system X synchronization with coaxial socket on the top cover, none accessory shoe
flash indication none aperture reflection into view finder none
general comments
bulletengraved: large Ernemann tower
bulletNone signature at the front
bulletat the bottom stamped with Germany USSR Occupied
collection data
Hummel-No 096c (Schulz-version:20) Kadlubek-No. ZIK 5220
body no. 77051 lens no. 4854753
lens type Jena T 1:2,8/50 (Tessar) purchase price 150€
advertising   manual

under construction
